Super Duty Alignment Lifts

The safest most versatile alignment lift on the market - and we invented it !!

Hydra "Open Beam" lifts give maximum access to the vehicle. No cumbersome beam or crossmember impedes the operator in any way when servicing the underside of the vehicle. There is no center section in the front traverse beam making it unique in the industry. By eliminating this section the operator has full access to the front underside of the vehicle and the ability to walk through with out obstructions. It can be installed on any reasonably level concrete surface Simply plug it in for a 12,000 lb. lift!! Standard packaging includes Rear Slip Plates, and turn plate cut outs.

Hydra-Lifts are built under the strictest of quality control procedures to meet or exceed the ANSI ALCTV-1998 standards to assure you full value for your money!!

Model 98 Open/Closed Beam
  • 12,000 lb. capacity with a special walk through design, clear floor, and a 69" lifting height.
  • 20 point automatic on multilevel locking system allows alignment service at any height. Unlock at the touch of a button.
  • Convenient control center allows you to raise, lower, and level lift from one position.
  • Extra wide 22" runways by 17 feet long to handle Cars, Pick Up Trucks and most RV's.
  • Built in full floating 60" rear slip plates for 4 wheel alignment and front turn plate cut outs accepting most brands of radius plates.
  • Built in air lines with outlets at either end of the
    lift for Jacks and tools.
  • Full length Jacking rails are standard. Optional 6000 lb. capacity Jacks available.
  • Built in hydraulic cylinder design means no overhead obstructions and doors open freely.
  • Elevator quality cables throughout, safety tested to over 5 times their normal load.
  • Quality all steel roller bearings for reduced wear and durability.
  • Front wheel stops and wheel chocks are supplied. An optional drive through design also available.
  • Compatible with all computer alignment systems and in rack wiring kits.
  • Complete with a unique Air Oiling system for durability.
